AOA-2405AM
Antenna
AOA-2405AM
2.4GHz 5dBi Outdoor Omni Mesh Antenna
- Frequency
- 2.4 GHz ~ 2.5 GHz
- Gain
- 5 dBi
- Connector
- N Male
- Impedance
- 50 Ω
Product details
Overview
AOA-2405AM
2.4GHz 5dBi Outdoor Omni Mesh Antenna
Installation illustration
Features
- RoHS Compliant
- Low V.S.W.R / Low Loss Design
- High Efficiency and Sensitivity
- Matching Free Design
2D Drawing Dimension
Specification
Test Report
Return Loss
V.S.W.R
Radiation Pattern
Technical details
Specifications
AOA-2405AM
|
Frequency |
2.4 GHz ~ 2.5 GHz |
|
Impedance |
50 Ω |
|
S.W.R |
<= 2.0 |
|
Gain |
5 dBi |
|
Radiation |
Omni |
|
Connector |
N Male |
|
Material |
UV Plastic |
|
Length |
166.5 mm |
