AUCM5G-SDX62
5G Global Bands USB-C modemQualcomm Solution
- Interface
- USB Type-C with USB 2.0 backward compatibility 1x micro-SIM slot 1x mini-SIM slot
- Antenna connector
- 2x external SMA connectors
- Embedded module
- SIMCOM SIM8260G-M2 (Qualcomm SDX62)
- Cellular network
- 5G Sub-6 CA / 4G (LTE MIMO 4x4, 3CA) / 3G
Overview
AUCM5G-SDX62
AUCM5G-SDX62 is a travel-ready 5G global USB modem
Global Bands is perfect for travelersand users looking for the fastest mobile data communication.
AUCM5G-SDX62 come with a 2-in-1 USB-C and USB-A universal and convenient USB cable; it is suitable for any PC/laptop/machine.
AUCM5G-SDX62 has 2x internal antenna and 2x external SMA antenna connector to allow extension RF cable with the high gain antenna to connect the far telecom 4G/5G base station.
Key features
-
SIM8260G-M2 5G M.2 modem
-
USB Type-C interface
-
4x LEDs
-
Mechanical switch for SIM selection
-
SIM slot door
-
2x external detachable antenna
-
2x internal antenna
- Screen clip
Specifications
Specifications
AUCM5G-SDX62
|
Embedded module |
SIMCOM SIM8260G-M2 (Qualcomm SDX62) |
|
|
Cellular network |
5G Sub-6 CA / 4G (LTE MIMO 4x4, 3CA) / 3G |
|
|
Data transfer |
5G NR DL/UL: 2.77 Gbps / 1.25 Gbps 4G DL/UL: 600 Mbps / 150 Mbps 3G DL/UL: 42.2 Mbps / 11.5 Mbps |
|
|
Frequency bands |
5G: SA Bands: n1/n2/n3/n5/n7/n8/n12/n13/n14/n18/n20/n25/n26/n28/n19/n30/n38 /n40/n41/n48/n66/n71/n75/n76/n77/n78/n79 4G: B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/ B29/B30/B32/B34/B38/B39/B40/B41/B42/B43/B46/B48/B66/B71 3G: B1/B2/B4/B5/B8/B19 |
|
|
GPS |
Standard: GPS/GLONASS/BeiDou/Galileo Bands: L1 |
|
|
Interface |
USB Type-C with USB 2.0 backward compatibility 1x micro-SIM slot 1x mini-SIM slot |
|
|
Antenna connector |
2x external SMA connectors |
|
|
Antenna |
2x detachable antenna 2x built-in antenna |
|
|
Switch |
1x slide switch (SIM select) |
|
|
LED |
1x modem status 1x micro-SIM 1x mini-SIM 1x power |
|
|
Button |
1x push-button (modem reset) |
|
|
Operating systems |
Windows Linux |
|
|
Power consumption (max.) |
12.53W |
|
|
Operating temperature |
-22°F ~ 158°F (-30°C ~ 70°C) |
|
|
Dimensions |
3.54 x 1.88 x 0.75 inch's (90 x 48 x 19 mm) |
|
|
Weight |
0.11 lbs. / 50 g |
|
