AP121

AP121


  • High Speed Data Rates

  • Providing faster data rates of up to 150Mbps and
    is compatible with legacy 802.11b/g equipment

  • Advanced Robust Security

  • Firewall with SPI to protect the internal host from
    hacker attacks. Wireless security is
    comprehensive and included WPA/WPA2 PSK

  • Feature Rich

  • WDS, Dual SSIDs, Static Routing, QoS and more


Application

Physical Description:

Front View Back View

| | | ------------------------- | ------------------------------------------------------------------------------------------------------------------------------------------------------- | | Standard | IEEE 802.11b/g/n | | Antenna | 5dBi detachable antenna | | Security | 64/128bit WEP
WPA(TKIP with IEEE 802.1x)
WPA2(AES with IEEE 802.1x)
WPA Mixed | | Sensitivity | 802.11b 11Mbps: -90
802.11g 54Mbps: -75
802.11n ( 20MHz) MCS7 : -71 | | Interface | RP-SMA antennas connector x 1
RJ-45 WAN port x 1
RJ-45 LAN ports x 1 | | Operation
Temperature | -20°C ~ 60°C | | Dimension | 93 x 70 x 26 mm | | Operation
Mode | Router
Bridge
Wireless ISP | | Frequency
Band | 2.400GHz ~ 2.484GHz | | Data Rate | 802.11n ( 40MHz ):
up to 150Mbps
802.11n ( 20MHz ):
up to 72Mbps
802.11g:
54,48,36,24,18,12,9,6Mbps
802.11b:
11,5.5,2,1Mbps | | Tx Power | 20dBm | | Power requirement | DC Jack:
5V DC( standard),
12V DC(option )
PoE: 12V Passive PoE | | Storage
Humidity | 10% ~ 90% (Non-condensing) | | Weight | 74g |
