AP121F

AP121F

AP121F



Easy Travel

Ultra compact streamlined stylish design to easy carry with you when you travel to anywhere

USB Powered

Simply Powered by USB standard type A connector, easy to powered by laptop or power bank, no power supply needed

High-Speed Wireless

High-speed IEEE 802.11n up to 150 Mbps


Application Scenario

  • WiFi Extender mode (such as Hotspot, Coffee shop Application)


  • WiFi Router mode (such as Hotel Application)


Chipset AR9331
Standard IEEE 802.11b/g/n
Frequency Band 2.4 GHz ISM Band
Flash 16 MB
SD-RAM 64 MB
Data Rate 802.11b:Up to 11 Mbps
802.11g: Up to 54 Mbps
802.11n: Up to 150 Mbps
Antenna Integrated antenna
TX Power 802.11b: 17 dBm
802.11g: 15 dBm
802.11n: 15 dBm
Receive Sensitivity -91 dBm@802.11b
-82 dBm@802.11g
-70 dBm@802.11n
WiFi Security WEP 64/128
WPA-PSK
WPA2-PSK
802.1x
LED WiFi/ LAN / VPN
Interface 1x RJ45 Ethernet WAN/LAN Port
1x USB flip cable
1x Reset button
1x Switch
Dimension 65 x 15.25 x 21.25 mm
Power USB 5V / 500 mA
Operating Temperature -20 ℃ - 65 ℃
Storage Temperature -10 ℃ - 70 ℃
Humidity 5% - 90% (non-condensing)
