APOE03

APOE03


  • upport Fast Ethernet assive PoE-enable device (PIN 1/2/3/6 Data. PIM4/5/7/8 Power)
  • Provide both data and electrical power to Passive PoE-enabled device
  • Support Wide Range input/output DC Power (5V – 57V at Max.48W)
  • Dual DC Power Input – 3-pin screw Terminal Block and power Jack
  • all mount ability

Power PIN 4/5, 7/8
Data PIN 1/2 , 3/6
Data In Connects PC/HUB/Switch
Ethernet Data Rate 10/100Tx Mbps
Ethernet Cable Cat.5 / Cat.5e / Cat.6
hernet Cable Connector RJ45
Support Input Voltage 5V – 57V (Max.48W)
Support Output Voltage 5V – 57V (Max.48W)
Built-In LED Indicators Power
Operating Temperature -20°C ~ 60°C
Storage Temperature -40°C ~ 75°C
Operating Humidity 10% to 80% Non-Condensing
torage Humidity 5% to 90%
Non-Condensing Power Supply 110 – 220V AC Power ; 5V – 57V
DC input
Unit Dimensions 676724mm (WLH)
Unit Weight 40g
