• Ultra compact, streamlined, stylish design
  • Plug-n-Play, self-contained, no driver installation
  • USB Powered - no power supply needed
  • Easy URL - no more setup IP addresses or complicated configurations

Stowable USB connector

3-mode network access: Anytime, anywhere Internet access

Hardware Interfaces

WAN / LAN 1 x 10Base/100M Base-TX
USB 1 x USB 2.0, type A connector
WLAN IEEE 802.11n 1T1R Max. 150Mbps (802.11b/g backward compatible)
LED WLAN x1 , Ethernet x1 , Power x1
Antenna Internal antenna x 1, 1T1R
Sensitivity > -82dBm @ 802.11b, -76dBm @ 802.11g, -73dBm @ 802.11n

Product Operation

Operation Modes USB to Ethernet Adapter mode
Wireless Access Point (AP) mode
Wireless Router mode
Power Requirement 5VDC, 500mA
Operation Temperature / Humidity -20°C to 60°C / 10% to 90% Non-Condensing
Dimension (L x H x W) 65 x 15.25 x 21.25 mm

Software specification

Wireless LAN

WLAN data rate 802.11n (Max. 150Mbps), 802.11g (Max. 54Mbps), 802.11b (Max.11Mbps)
Antenna Internal antenna
Operation Frequency 2.400~2.483GHz
Security WEP 64 or 128 bit/WPA/WPA2/WPA2 Mixed, WPS, WDS

Router Mode Features

NAT DMZ Host, Port-Redirection/Virtual server / Universal Plug-and-Play /
Dynamic Domain Name System (DDNS) / VPN pass-trough
Firewall Policy-Based IP Packet Filter, Port filter, MAC address filtering,
URL filter, System logging via Syslog
QoS IP, MAC address, guarantee bandwidth QoS configurations


  • Web-based GUI for remote and local management
  • Syslog monitoring support
