AOA-M4G

AOA-M4G




Frequency Range 698-960 MHz
1710-2700 MHz
Gain 4/6 dBi
VSWR <1.5
Radiation Omni Direction
Horizontal Beam width 360º
Vertical Beam width 18º
Polarization Vertical
Maximum Input Power 100 W
Impedance 50 ohm
Connector N Female
Antenna Material Fiberglass
Mount type Pole
Diameter of Installation Pole Ø30 - Ø50 mm
Dimensions Ø63 x 220 mm
Weight 1.2 kg
Operating Temperature -40ºC - 70ºC
Rated wind velocity 60 m/s
