AWUS036EAXM

AWUS036EAXM

AWUS036EAXM is a high-performance WiFi 6/6E (802.11ax) 2x2 Tri-band USB adapter, engineered to unlock the full potential of the 2.4 GHz, 5 GHz, and the newly available 6 GHz bands. When paired with a WiFi 6E or WiFi 7 router, it delivers blistering speeds of up to 3000 Mbps, ensuring ultra-low latency for high-definition streaming and online gaming. While pushing the boundaries of wireless speed, it remains fully backward compatible with WiFi 5 and WiFi 4 networks.
Additionally, the integrated Bluetooth v5.2 technology provides a superior wireless audio experience, offering higher-quality sound and more stable connections for your headphones and speakers.



Key features

  1. Trip-band 2.4 GHz / 5 GHz / 6 GHz
  2. Maximum data rate up to 1800 Mbps
  3. Backward compatible with 802.11a/b/g/n/ac
  4. Bluetooth v5.2
  5. Integrated Wi-Fi + BT antenna
  6. USB-A connector supports USB 3.2 GEN 1



Specifications

Chipset

MediaTek MT7921AUN

IEEE 802.11 standards

a/b/g/n/ac/ax

Bluetooth

5.2

Frequency

2.4 GHz

5 GHz

6 GHz

Data rate

2.4 GHz up to 600 Mbps

5 GHz up to 1200 Mbps

6 GHz up to 1200 Mbps

USB connector

USB 3.2 Gen 1 Type-A

Wi-Fi antenna

1.5 dBi @2.4 GHz

2 dBi @5 GHz

2 dBi @6 GHz: 2

Bluetooth antenna

1 dBi

Power consumption

2.7 Watts (max.)

Dimensions

87.4 x 28.5 x 12 mm (3.44 x 1.13 x 0.47 inches)

Operating temperature

-20° C - 70° C (-4° F - 158° F)

Operation voltage

5 V

OS support

Windows 10/11 & Linux
